Hot air soldering rework station with digital display BST-702D

Model Number: 702D
Temp.Control:: 100℃-500℃
Output Power for hot gun: 650W±10%
Heating wire for hot gun: High-power heating wire
Heater of soldering iron: Four core ceramic heater
Packing size:56.5cm*34cm*60.5CM
The number of packing: 6 units
A carton weight: 26.6KG

1. 702 hot air soldering station adopt sensor close loop,microcomputer control the temperature,LED display.
2. high-power,rapid heating,accurate and stable temperature.
3. The airflow is adjustable,the wind is heavy but soft.and the hot air gun is made of heat-resisting material.
4. When the power is off, the cool system will work automatically.
5. The solder iron heat rapidly,the temperature can be ajustable,the hand is very light and handy

Application:
1. Three different size nozzle, which can be used for different size of BGA,SMD,PCB.
2. This item has widely usage,can be used for electronic factory,repairing ect.

Switchboard
Rated voltage：	AC 220V±10% 50Hz
Total Power：	650W±10％（Max）
Work Environment：	0～40℃ Relative humidity＜80％
Storage Temperature：	－20～80℃ Relative humidity＜80％

Hot air gun parts
Operating Voltage：	AC 220V±10% 50Hz
Output Power：	650W±10％
Temperature Range：	100℃～500℃
Gas type：	Pump air
Gas flow：	24L/min(Max)
Temperature stability：	±2℃ （Static state）
Setting mode：	Buttons to adjust
Display：	LED Digital
Temperature lock mode：	Touchtone
Noise：	Less than 45dB
Nozzle specifications：	A1124、A1125、A1130
Heating wire：	High-power heating wire

Solder Equipment
Operating Voltage：	AC 26V±10% 50Hz
Output Power：	40W±10%
Temperature Range：	200℃～480℃
Temperature stability：	±2℃ Static state）
Setting mode：	Buttons to adjust
Display：	LED Digital
Temperature lock mode:	Touchtone
Tip-to-ground impedance：	＜2Ω
Tip-to-ground voltage：	＜2mV
Tip：	BST900-M-T-I
Heater：	Four core ceramic heater

Packing specifications
Body weight：	4.26KG
The box size：	332720.5CM
Packing size：	56.5cm34cm60.5CM
The number of packing：	6 units
A carton weight：	26.56KG
Fitting:	A wire rack; one iron ;one iron seat ;3 nozzle ; one puller ; air gun rack; one manual
